Excel Power XL-DC-220 200kVA Diesel Generator

Key Features

Excel Power XL-DC-220 200kVA Diesel Generator

200kVA – 160kW Prime Power / 220kVA – 176kW Standby Power
3-Phase generator 400V – 50HZ
High quality water cooled 1500RPM Cummins diesel engine
High quality Stamford alternator
Deepsea DSE6120 control panel for easy operation
Bunded fuel tank with 8-hour runtime
12 month warranty or 1000 hours

View all features

Request a quote

Call For Lead Time

Description
Specifications
Delivery

The Excel Power XL-DC-220 200kVA Diesel Generator.

The Excel Power XL-DC-220 200kVA Diesel Generator is a cornerstone of the Excel Power Standby Range, engineered to deliver unwavering performance during power outages. Designed for permanent installation in commercial facilities, private residences, and industrial sites, this 200kVA generator ensures continuity when mains power fails. Combining a robust Cummins engine with a high-efficiency Stanford alternator plus a 8-hour runtime fuel tank, the Excel Power XL-DC-220 is built to withstand rigorous standby duty while prioritising fuel

...

Key Specifications at a Glance

Prime Power Output: 200kVA (continuous operation)
Standby Power Output: 220kVA (emergency backup)
Engine: Cummins Water-Cooled Diesel Engine, 1500rpm
Alternator: Stanford Brushless, Class H Insulation
Control Panel: Deepsea DSE6120 (Fully Automated)
Voltage Regulation: ±1% via Sealed Automatic Voltage Regulator (AVR)
Runtime: 8+ Hours (Bunded Fuel Tank)
Noise Reduction: Close-Fitting Acoustic Canopy
Warranty: 12 Months or 1000 Hours (Whichever Occurs First)

Unmatched Power Performance Prime Power 200kVA | Standby Power 220kVA

The Excel Power XL-DC-220 operates at 1500rpm, balancing fuel efficiency with optimal torque for both prime and standby applications. In prime power mode, this 200kVA generator supports continuous operation for construction sites, data centres, or agricultural operations. In standby power mode it can produce 220kVA output, ensuring critical systems like medical equipment, HVAC, or security infrastructure remain functional during grid failures.

Heavy-Duty Engine & Alternator: Built for Endurance Cummins Water-Cooled Diesel Engine

At its core lies a Cummins diesel engine renowned for durability and low emissions. The water-cooled design ensures consistent thermal management, even under extended loads, while 1500rpm operation minimises wear and fuel consumption.

Stanford Alternator with Anti-Vibration Mounts

Coupled to the engine is a Stanford alternator. Both components are mounted on anti-vibration dampers, reducing mechanical stress and noise transmission for smoother operation.

Deepsea DSE6120 Control Panel: Smart Automation

The generator is managed by a Deepsea DSE6120 control panel, offering:

Automatic Start/Stop: Activates during outages without manual intervention.
Real-Time Monitoring: Track voltage, frequency, coolant temperature, and oil pressure.
Fault Diagnostics: Instant alerts for issues like low oil or overheating.
Remote Control Compatibility: Integrate with building management systems.

Precision Voltage Regulation & Noise Control ±1% Voltage Stability

A fully sealed AVR ensures voltage remains within ±1% of the setpoint, protecting sensitive electronics from fluctuations.

Acoustic Canopy for Ultra-Low Noise

The close-fitting acoustic canopy reduces noise levels, making the 200kVA genset suitable for residential areas or noise-sensitive environments. Optional Ultra-Low Noise Canopies further dampen sound for critical applications, contact us for further information.

Bunded Fuel Tank & Extended Runtime

The integrated bunded fuel tank offers an 8-hour runtime, with a secondary containment layer to prevent spills. For extended operation, explore external tank upgrades (500L to 10,000L capacities).

Standard Features for Immediate Readiness

Coolant Heater: Preheats the engine for instant starts in cold climates.
Battery Charger: Maintains battery health during idle periods.
Anti-Corrosion Coatings: Protects against harsh environments.

Upgrade Options for Enhanced Functionality

Customise your 200kVA Diesel Generator with:

Three-Way Valves: Simplify fuel line maintenance.
Control Panel Upgrades: Add GSM monitoring or parallel operation.
Automatic Transfer Switches (ATS): Seamlessly transition between grid and generator power.
AREP (Alternator Auxiliary Winding): Ideal for heavy motorised loads.

Warranty & Support

Backed by a 12-month/1000-hour warranty, the XL-DC-220 reflects Excel Power’s commitment to quality. Extended warranties and service plans are available.

Excel Power XL-DC-220 200kVA Diesel Generator – Reliable Standby Power for Demanding Applications
The Excel Power XL-DC-220 200kVA Genset merges industrial-grade engineering with user-centric design. Whether safeguarding a hospital, factory, or home, its Cummins engine, Stanford alternator, and smart controls deliver peace of mind.

Contact Us Today

Discuss your needs for a 200kVA Diesel Generator or explore upgrades like ATS, external tanks, or ultra-quiet canopies, and maintenance and service plans. Our team is ready to tailor a solution for you.

Manufacture Excel Power
Model XL-DC-220
Output rating 50HZ 400/230V, 1500RPM
Prime Power 200kVA / 160kW
Standby Power 220kVA / 176kW
Noise Level: TBAdB(A) at 7m in free field conditions.

Engine Technical Data:

Engine make: Cummins
Engine model: 6CTAA8.3-G2
Governing type: ECU / ELEC
Number of cylinders: 4
Cylinders arrangement: In-line
Aspiration: NA
Cycle: 4-Stroke
Cooling system: Water- Cooling
Frequency & engine speed: 50HZ & 1500RPM

Alternator Data:

Make: Stamford
Model: UCI274H
No. of Bearings: 1
Insulation Class: H
Ingress protection: IP23
Excitation system: Shunt
Voltage: ±1%

Dimensions :

Length (mm): 3260
Width (mm): 1100
Height (mm): 2000
Weight* Kg: 2700
Fuel tank capacity: 8 (H)

Control Panel:

Make: Deepsea
Model: DSE6120

Connection Type: :

TBA - 3 phase
